Mains choke N CNW 903

Three-phase line reactor 4% Uk

DESCRIPTION

NEW SERIES!

The new series not only scores points for its faster delivery time, but also for its resource conservation and increased efficiency.

Power Noise Reduction – save up to 20% energy costs. A line reactor relieves the supply network by compensating the harmonics reactive power. The harmonics and commutation notches are reduced strongly. By using a line reactor the inverter electronics and DC-capacitors will be protected.

Starting currents and current peaks are reduced up to 60%. Line reactors help to comply with international power quality standards IEEE 519 or EN 61000-3-2.

ADVANTAGES

Compact design
Extended service life of electrical consumers
Low-temperature rise
Attenuation of current spikes up to 60%
Reduction of input current up to 20%
Low-noise
Production possible according to UL insulation system E251513

TYPICAL APPLICATIONS

Drive systems for motor drives, Mechanical engineering, Elevators / escalators, Pipes, Conveyor technology, Ventilation and air conditioning, Robotics, Automation technology, Power supplies, Wind turbines

Technical Data

Rated voltage: U ≤ 3 x 500 V
Short circuit: U_k 4% (400VAC/50Hz, I_Nenn)
Frequency: 50/60 Hz
According to: EN 60289 / EN 61558
Test voltage: L-L 2500 V, DC 1min; L-PE 2500 V, DC 1min
Insulation class: T40/F
Protection rating: IP 00
Climatic category: DIN IEC 60068-1
Overload: 1,5 x I_Nenn 1 min / h
Design: standing on foot angle

TECHNICAL SPECIFICATION

Type	Nominal voltage / nominal frequency UN [V]	Nominal current IN [A]	Inductance L [mH]	Losses P [W]	Mass [kg] [kg]	Weight Cu [kg	Weight Al [kg]
N CNW 903 /3	500 50 / 60 Hz	3	9,800	16	1,0	0,2
N CNW 903 /6	500 50 / 60 Hz	6	4,880	25	2,0	0,3
N CNW 903 /8	500 50 / 60 Hz	8	3,680	35	2,0	0,3
N CNW 903 /10	500 50 / 60 Hz	10	2,930	36	3,0	0,4
N CNW 903 /12	500 50 / 60 Hz	12	2,450	38	3,0	0,5
N CNW 903 /16	500 50 / 60 Hz	16	1,830	48	4,0	0,7
N CNW 903 /25	500 50 / 60 Hz	25	1,170	63	5,2	0,8
N CNW 903 /36	500 50 / 60 Hz	36	0,810	67	7,o	1,9
N CNW 903 /50	500 50 / 60 Hz	50	0,590	112	9	1,2
N CNW 903 /70	500 50 / 60 Hz	70	0,420	180	11	2,1
N CNW 903 /90	500 50 / 60 Hz	90	0,330	144	17	2,5
N CNW 903 /110	500 50 / 60 Hz	110	0,270	179	18	2,8
N CNW 903 /125	500 50 / 60 Hz	125	0,235	220	17	2,6
N CNW 903 /160	500 50 / 60 Hz	160	0,180	145	22	5,0
N CNW 903 /200	500 50 / 60 Hz	200	0,147	187	26	1,3	3,8
N CNW 903 /250	500 50 / 60 Hz	250	0,118	254	35	1,3	3,0
N CNW 903 /300	500 50 / 60 Hz	300	0,098	250	37	1,3	4,7
N CNW 903 /350	500 50 / 60 Hz	350	0,084	267	45	2,6	5,0
N CNW 903 /400	500 50 / 60 Hz	400	0,074	365	52	2,6	5,2
N CNW 903 /500	500 50 / 60 Hz	500	0,059	423	58	2,9	7,8
N CNW 903 /600	500 50 / 60 Hz	600	0,049	450	71	5,0	6,9
N CNW 903 /700	500 50 / 60 Hz	700	0,042	493	88	5,0	9,2
N CNW 903 /800	500 50 / 60 Hz	800	0,037	545	96	5,1	8,3
N CNW 903 /900	500 50 / 60 Hz	900	0,033	655	108	12,5	10,1
N CNW 903 /1000	500 50 / 60 Hz	1000	0,029	775	108	12,5	10,1
N CNW 903 /1200	500 50 / 60 Hz	1200	0,024	1009	133	13,9	12,4

DIMENSIONS IN MM

Type	Lenght L1 (mm)	Lenght L2 (mm)	Broad B1 (mm)	Broad B2 (mm)	High max. H1 (mm)	Mounting N1 (mm)	Attachment N2 (mm)	Attachment D1 (mm x mm)	Clamps/Cross section [mm²]	Connection Angle (mm x mm)	Connection A1 (mm)	Connetion D2 (mm)	Connection PE
N CNW 903 /3	65	78	50	60	95	50	38	5 x 8	2,5				M4
N CNW 903 /6	80	96	55	65	110	56	43	5 x 8	2,5				M4
N CNW 903 /8	125	120	61	66	130	100	45	5 x 8	2,5				M4
N CNW 903 /10	125	120	71	76	130	100	55	5 x 8	2,5				M4
N CNW 903 /12	125	120	71	76	130	100	55	5 x 8	2,5				M4
N CNW 903 /16	155	150	76	76	155	130	54	8 x 12	2,5				M4
N CNW 903 /25	155	150	91	101	170	130	69	8 x 12	10				M4
N CNW 903 /36	190	180	81	91	195	170	57	8 x 12	10				M6
N CNW 903 /50	190		130		160	170	77	8 x 12	16 (M6)		45		M6
N CNW 903 /70	230		136		200	176	73	9 x 13	16 (M8)		45		M8
N CNW 903 /90	230		150		200	176	95	9 x 13	16 (M8)		45		M8
N CNW 903 /110	240		150		210	185	97	10 x 18	16 (M8)		45		M8
N CNW 903 /125	240		150		210	185	95	10 x 18	16 (M8)		45		M8
N CNW 903 /160	240		175		210	185	103	10 x 18	35 (M10)		55		M8
N CNW 903 /200	300		148		270	224	95	10 x 18		30 x 4	39	11	M12
N CNW 903 /250	300		184		270	224	125	10 x 18		30 x 4	39	11	M12
N CNW 903 /300	300		190		270	224	125	10 x 18		30 x 4	39	11	M12
N CNW 903 /350	340		192		305	248	130	10 x 18		40 x 5	49	13	M12
N CNW 903 /400	360		195		315	264	142	10 x 18		40 x 5	49	13	M12
N CNW 903 /500	360		200		345	264	142	10 x 18		40 x 5	49	13	M12
N CNW 903 /600	360		232		345	264	167	10 x 18		40 x 5	58	13	M12
N CNW 903 /700	420		240		370	316	174	13 x 20		40 x 5	58	13	M12
N CNW 903 /800	420		275		380	316	184	13 x 20		60 x 5	68	2 x 13	M12
N CNW 903 /900	480		263		465	356	158	13 x 20		60 x 10	78	2 x 13	M12
N CNW 903 /1000	480		263		465	356	158	13 x 20		60 x 10	78	2 x 13	M12
N CNW 903 /1200	480		265		500	356	168	13 x 20		60 x 10	78	2 x 13	M12
